ceiling-mounted stove
Andorra
Our Andorra model is a ceiling-mounted combination stove that, with its slim, modern design, becomes a stylish highlight in any living space. With a variable overall height from 203 to 436 cm, it flexibly adapts to different room heights. For maximum versatility, you can operate it either with firewood or with the power-free KO6 Pellet System Insert – depending on your mood or needs. On request, the Andorra is also available with a rotating function, allowing you to enjoy the fire from any angle. Additionally, we offer an optional sloped-ceiling mount as well as an intermediate ceiling penetration – perfect for special structural requirements.
- Heat release
- up to 4 h
- Nominal heat output
- 8.6 kW
- Efficiency
- 81 %
Andorra, ceiling-mounted stove
Why the Andorra
The Andorra in detail
Wood or pellets, no electricity
With KO6 you can also heat with pellets – no fan, no power connection.
KO6: 2.2 kg per filling
OptionalDetails on our pellet systemMore heat storage on request
An additional heat storage block extends the heat release.
Storage block available as an option
OptionalWarmth that lasts
Heat continues to be released for hours after the fire has burned down.
Burn time up to 0.8–1.6 h · heat release up to 4 h
Rotatable
Turn the stove so you can see the fire from your favourite spot.
Values from the technical data. Heat release depends on factors such as room, insulation, fuel and operation.
| Value | Firewood/briquettesstandard | Pellets KO6optional · 2.2 kg |
|---|---|---|
| Nominal heat output | 8.6 kW | 7 kW |
| Efficiency | 81 % | 85 % |
| Space heating capacity | 70–210 m³ | 35–100 m³ |
| Fuel | 2.8 kg/h | 2.2 kg |
| Burn time | up to 0.8–1.6 h | up to 1.2–2 h |
| Heat release | up to 4 h | up to 4 h |
| Flue gas temperature | 225 °C | 225 °C |
| CO (13 % O₂) | ≤ 1250 mg/m³ | 594 mg/m³ |
| Dust (13 % O₂) | ≤ 40 mg/m³ | 17 mg/m³ |
Values from the technical data. Pellet system inserts are optional accessories. Heat release depends on factors such as room, insulation, fuel and operation.
- Firebox
- H 68 × W 26 × D 30 cm
- Viewing window
- H 80 × W 39 cm
- Fire door
- H 80 × W 39 cm
- Fireclay
- 17.5 kg
Installation and connection
- Distance to combustible materials
- rear 40 cm · side 50 cm · front 90 cm
One stove.
Two fuels.
Your Andorra – fired with logs or with wood pellets. For pellet operation, a pellet system insert is placed in the combustion chamber. No electricity required.
- No power connection needed for pellet operation
- No electricity
- Pellets per filling (KO6)
- 2.2 kg
- Heat release (KO6)
- up to 4 h
- Nominal heat output with logs
- 8.6 kW
- Burning time with logs
- up to 0.8 h
- Heat release with logs
- up to 4 h
Values according to the technical data of the model.
Pellet firing made easy – without electricity
The video shows how a pellet system insert works in the combustion chamber.
Suitable for Andorra:
Data and facts
Technical data
| measurements (cm) | H x W x D 163-436 x 35 x 35 cm |
| combustion chamber | H x W x D 68 x 26 x 30 cm |
| fire glass | H x W 80 x 39 cm |
| fire door | H x W 80 x 39 cm |
| total weight | from 131 kg |
| chamotte bricks | 17,5 kg |
Data for firewood
| nominal heat output | 8,6 kW |
| efficiency | 81% |
| heating capability | 70 - 210 m³ |
| amount of fuel | 2,8 kg / h |
| fire duration | up to 0,8 - 1,6 h |
| heat release | up to 4 h |
| flue gas flow volume | 11,0 g/s |
| exhaust °C (nozzle) | 225 °C |
| min/max feed press. | 12 / 15 Pa |
| CO (13%O2) | ≤ 1250 mg/m³ |
| dust (13%O2) | ≤ 40 mg/m³ |
| NOx (13%O2) | ≤ 200 mg/m³ |
| OGC (CxHy) (13%O2) | ≤ 120 mg/m³ |
Data for Pellet System Insert KO6
| nominal heat output | 7 kW |
| output range | 7 - 5 kW |
| efficiency | 85% |
| heating capability | 35 - 100 m³ |
| amount of fuel | 2,2 kg |
| fire duration | up to 1,2 - 2 h |
| heat release | up to 4 h |
| flue gas flow volume | 9,40 g/s |
| exhaust °C (nozzle) | 225 °C |
| min/max feed press. | 12 / 15 Pa |
| CO (13%O2) | 594 mg/m³ |
| CO (13%O2) | 0,048 % |
| dust (13%O2) | 17 mg/m³ |
| NOx (13%O2) | 98 mg/m³ |
| OGC (CxHy) (13%O2) | 14 mg/m³ |
Distances to combustible walls / components
| wall distance, rear | 40 cm |
| wall distance, side | 50 cm |
| distance to the front | 90 cm |
